Mueller® 350 psi Resilient Wedge A-2361 Gate Valves. Sizes 3″-12″

Catalog Numbers:

• • A-USP1-16 mechanical joint x flanged ends (with accessories unassembled)
  • A-USP1-19 mechanical joint x flanged ends (less accessories)

Specifications:

• Sizes – 3″, 4″, 6″, 8″, 10″, 12″
• Meets or exceeds all applicable requirements of ANSI/AWWA C515*** Standard, UL 262 Listed, FM 1120/1130 Approved, and certified to ANSI/NSF 61 & 372
• Flanged end drilling complies with ASME/ANSI B16.1 Class 125
• Mechanical joint end complies with ANSI/AWWA C111 Standard
• Iron body with nominal 10 mils Pro-Guard®Fusion Bonded Epoxy Coated interior and exterior surfaces
• Epoxy coating meets or exceeds all applicable requirements of ANSI/AWWA C550 Standard.
• Iron wedge, symmetrical & fully encapsulated with molded rubber; no exposed iron
• Non-rising stem (NRS)
• Triple O-ring seal stuffing box (2 above the thrust collar and 1 below)
• 2″ square wrench nut–open left or open right
• 300 psig (2000 kPa/20 barg) maximum working pressure, 600 psig (4100 kPa/ 41 barg) static test pressure
• UL Listed, FM Approved: 300 psig (2000 kPa/20 barg)
• Designed for potable water applications

Options*:

• Position indicators
• Stainless steel stem: Type 304, Type 316
• EPDM Disc and O-rings
• Low zinc, silicon bronze ASTM B98-C66100/H02 stem
• Handwheel
